Radio frequency Connector G5188623024

High-Reliability RF Coax Connector for Mission-Critical Systems

Built on the robust “Radio frequency Connector G5188623024” platform, this high-reliability RF Connector is engineered for stable, low-loss signal transmission in demanding environments. Featuring a precision-machined coaxial interface, full EMI shielding cover, and integrated die-cast heat sink, it ensures consistent performance under high power, wide temperature swings, and intense electromagnetic noise. It serves as a dependable Coax Connector solution and a rugged implementation of standard RF Type interfaces for defense, industrial, and telecom infrastructure.

Key Features

• Die-Cast Heat Sink Integration: Efficiently dissipates thermal energy during continuous high-power operation.
• 360° EMI Shielding Cover: Provides complete electromagnetic isolation to preserve signal fidelity.
• Military-Grade Construction: Sealed housing with corrosion-resistant plating for extreme durability.
• Precision Impedance Matching: Maintains 50 Ω nominal impedance across its full frequency range for minimal VSWR.

Technical Specifications

• RF Type: N-Type (50 Ω) female jack (threaded coupling, compatible with standard N male plugs)
• Impedance: 50 ohms nominal
• Frequency Range: DC to 18 GHz
• VSWR: ≤1.25:1 (up to 10 GHz)
• Insertion Loss: ≤0.12 dB @ 6 GHz
• Power Handling: Up to 2 kW (at 2 GHz, sea level)
• Contact Material: Silver-plated beryllium copper
• Housing Material: Brass body with nickel plating and integrated aluminum die-cast heat sink
• Operating Temperature: -55°C to +125°C
• Ingress Protection: IP67-rated when mated with compatible cable assembly

Applications

These RF Connectors are ideal for:

• Cellular macro base stations requiring rugged Coax Connector reliability
• Military field radios and tactical communication systems using standardized RF Type interfaces
• Broadcast transmitters and satellite uplink equipment
• Industrial radar and remote sensing platforms
• Emergency response and public safety networks operating in harsh conditions

Frequently Asked Questions

Q: Is this connector suitable for outdoor installations?
A: Yes—when paired with an IP67-rated cable assembly, it withstands dust, rain, and temporary submersion.

Q: How does the die-cast heat sink improve performance?
A: It draws heat away from the center contact during high-power transmission, preventing thermal drift and maintaining signal stability.

Q: Can it be used in high-vibration environments like vehicles or aircraft?
A: Absolutely—the threaded N-Type coupling and solid metal construction provide excellent resistance to mechanical shock and vibration.

Combining proven N-Type reliability with advanced thermal and EMI management, this RF Connector delivers unmatched resilience for critical Coax Connector links and robust RF Type network deployments where failure is not an option.
