Liberation 10 tons tanker

10 month ago

38 0 

Hubei Ocean Automobile Industry Co., Ltd.

12 month

Product details

Chassis configuration: New J6L full floating flat-top row half cab, wheelbase 4700mm, hydraulic instrument, electric glass lift,

electric rearview mirror, driver seat for air shock absorption seat, middle seat, large diesel 220 horsepower (four-cylinder engine),

liberation 8-speed gearbox, axle Φ 378 impact welding bridge, speed ratio 4.875, Type 275/80R22.5 18-level tubeless,

automatic air conditioning, front lower protection device, aluminum fuel tank 300L, electrohydraulic lift, speed limit 79km/h,

exhaust tailpipe and muffler front, front disc rear wedge brake, airbag suspension, seat belt wearing reminder,

brake lining replacement alarm, Tire burst emergency safety device, U-shaped after-treatment, ESC, aluminum reservoir,

EBS(brake control system), LDW(lane departure warning), FCW(collision warning), single tire belt TPMS(tire pressure monitoring),

T-box 2.0, 60,000 km long oil change cycle.

Upper configuration: capacity 12.9 cubic meters, diesel and gasoline medium, tank thickness 5mm, head 5mm thick,

with pump inlet and pump outlet, with a full set of European standards (two European standard tank openings,

a submarine valve, a lower oil loading, a waste gas recovery, an anti-overflow probe rod and socket),

lower oil loading position according to the standard, equipped with submarine valve sound and light alarm system,

with electrostatic reel, a toolbox, with folding guardrail, equipped with a fire cap, two oil pipes with the same length as the tank,

two fire extinguishers, the rest of the factory standard.

Paint: silver-gray,(paste 3M reflective strip, reflective tape, three "flammable liquid" labels, safety notice.)

The vehicle is suitable for the transport of dangerous goods, transport dangerous goods vehicle type:FL type,

the maximum density of the transport medium 830 kg/cubic meters, total tank capacity 12.7 cubic meters,

effective tank volume 12.1 cubic meters.External size of tank body (long × long axis × short axis)(mm):5800×2200× 1430, 5700 ×2000×1400.

Optional: carbon steel tank, aluminum alloy tank
