Operation video of 4 ton crawler excavator
4 year ago
Shanding Mini Excavator SD40B TON
1.Yanmar engine
2.Low noise
3.Imported hydraulic system,working smoothly
Crawler Wheeled Excavators Crawler Wheeled Excavators Standard Crawler Excavators
|
Overall size |
|
|
Overall Length |
4600mm |
|
Overall Width |
1700mm |
|
Overall Height |
2400mm |
|
Platform turning radius |
1170mm |
|
Track Length |
2175mm |
|
Track Width |
300mm |
|
Gauge |
1620mm |
|
Boom Length |
2350mm |
|
Arm Length |
1230mm |
|
Min Ground Clearance |
260mm |
|
Platform Width |
1550mm |
|
Engine hood height |
1300mm |
|
Platform Height Above Ground |
570mm |
|
Machine parameters |
|
|
Machine Weight |
3650Kg |
|
Bucket Capacity |
0.2m³ |
|
Bucket Width |
600mm |
|
Rated Power |
34KW |
|
Rated Rotary speed of Engine |
2400r/min |
|
Hydraulic Pressure |
22MPa |
|
Max Grade |
35° |
|
Ground Pressure |
34.8kpa |
|
Max Travel Speed |
2.7/4.6Km/h |
|
Max Digging Force |
26KN |
|
Rotary Speed |
9-11rmp |
|
Working range |
|
|
Max. Digging Height |
4500mm |
|
Max. Dumping Height |
3050mm |
|
Max. Digging Depth |
3100mm |
|
Max. Sinking Depth of Bulldozer |
270mm |
|
Max Digging Radius |
4730mm |
|
Min. Radius of Gyration |
1820mm |
|
Max. Lifting Height of Bulldozer |
350mm |
|
Machine configure |
|
|
Model No |
SD40B |
|
Engine Model |
Changchai 490 |
|
Motors |
Imported motors |
|
Pump |
Variable piston pump |
