Automatic Wire Mesh Welding Machine.mp4
4 year ago
Working specifications: |
|
Material |
Smooth or ribbed weldable wires |
Max.mesh width(cross wire length) |
2,100[mm] |
Max.outmost line wire dimension |
2,000[mm] |
Max.mesh length(line wire length) |
4,000[mm] |
Line wire spacing |
50-300 [mm],multiples of 50 [mm] |
Cross wire spacing |
≥50[mm],programmable adjustable |
Line wire diameter |
Ф3-Ф6[mm](off-coil+pre-cut) |
Cross wire diameter |
Ф3-Ф6[mm](pre-cut) |
Max.welding capacity |
Ф6+Ф6[mm] |
Max.welding speed |
70-90[strokes/min](cross wire no°/min) |
Air consumption |
≥0.6Mpa,1.5m3/min |
Cooling water consumption |
≥0.2Mpa,0.5m3/min |
Electronic parts specifications: |
|
Numbers of welding transformer |
10 |
Numbers of electrode |
20 |
Power supply voltage |
380[V]-20[Hz]-3[Phase] |
Control voltage |
DC24[V] |
Total installed |
10×125[KVA] |
Short circuit voltage |
4-8[V] |
Welding current controlling |
transistor |
No. |
Components |
Quantity |
1 |
Line wire vertical pay-offs |
20 PCS |
2 |
Line wire positioning and straightening unit |
1 UNIT |
3 |
Line wire pulling unit |
1 UNIT |
4 |
Line wire loop & balancing unit |
1 UNIT |
5 |
Line wire (pre-cut) storage table table and pre-feeding device |
1 UNIT |
6 |
Line wire step-feeding unit |
1 UNIT |
7 |
Welding system |
1 UNIT |
8 |
Cross wire feeding unit(magazine) |
1 UNIT |
9 |
Mesh puller |
1 UNIT |
10 |
Mesh cutter |
1 UNIT |
11 |
Mesh turning and stacking unit |
1 UNIT |
12 |
Mesh conveyor |
1 UNIT |
13 |
Electric cabinet and control system |
1 UNIT |
14 |
Spare parts |
1 UNIT |
15 |
Tools |
1 UNIT |
16 |
User’s guide (English version) |
1 UNIT |
