Wire Mesh Welding Line -Pre cut type.mp4

Working specifications:

Material

Smooth or ribbed weldable wires

Max.mesh width(cross wire length)

2,100[mm]

Max.outmost line wire dimension

2,000[mm]

Max.mesh length(line wire length)

4,000[mm]

Line wire spacing

50-300 [mm],multiples of 50 [mm]

Cross wire spacing

≥50[mm],programmable adjustable

Line wire diameter

Ф3-Ф6[mm](off-coil+pre-cut)

Cross wire diameter

Ф3-Ф6[mm](pre-cut)

Max.welding capacity

Ф6+Ф6[mm]

Max.welding speed

70-90[strokes/min](cross wire no°/min)

Air consumption

≥0.6Mpa,1.5m3/min

Cooling water consumption

≥0.2Mpa,0.5m3/min

Electronic parts specifications:

Numbers of welding transformer

10

Numbers of electrode

20

Power supply voltage

380[V]-20[Hz]-3[Phase]

Control voltage

DC24[V]

Total installed

10×125[KVA]

Short circuit voltage

4-8[V]

Welding current controlling

transistor

No.

Components

Quantity

1

Line wire vertical pay-offs

20 PCS

2

Line wire positioning and straightening unit

1 UNIT

3

Line wire pulling unit

1 UNIT

4

Line wire loop & balancing unit

1 UNIT

5

Line wire (pre-cut) storage table table and pre-feeding device

1 UNIT

6

Line wire step-feeding unit

1 UNIT

7

Welding system

1 UNIT

8

Cross wire feeding unit(magazine)

1 UNIT

9

Mesh puller

1 UNIT

10

Mesh cutter

1 UNIT

11

Mesh turning and stacking unit

1 UNIT

12

Mesh conveyor

1 UNIT

13

Electric cabinet and control system

1 UNIT

14

Spare parts

1 UNIT

15

Tools

1 UNIT

16

User’s guide (English version)

1 UNIT
