Product Name: Din rail multi functional RS485 MID approved single phase solar energy meter

Elecnova din rail mounted energy meter DDS1946-2M single phase meter is a digital energy meter complies with the MID certification Class B (2014/32/EU). With the 32mm width (2DIN module) compact design, it’s right perfect for the fiscal metering for the home use wall mounted EV charger. The DDS1946-2M is equipped with a LCD display for parameter checking, the DDS1946-2M also has the standard Modbus-RTU communication protocol, the measuring data could be integrated with the display of the EV charger by RS485 interface.
Advantage
Technical Parameter
DDS1946-1P
DDSF1946-1P
DDS1946-2P
DDSF1946-2P
DDS1946
DDSF1946
DSS1946
DSSF1946
DTS1946
DTSF1946
Normal Voltage
230V
230V
230V
3*400V
3*230/400V

Current
Direct input
5(40)A
5(100)A
5(100)A
5(100)A
5(100)A
Via CT input
-
-
1.5(6)A
1.5(6)A
1.5(6)A
Accuracy
Class 1(Optional:Class 0.5S)
Frequency
45Hz~65Hz
Voltage Range
0.8Un~1.2Un

Start Current
Direct input
0.004Ib
Via CT input
0.002In
Consumption
<2VA
Energy Pulse
1 output, pulse width (80±20%) ms
RTC Error
≤0.5s/day
Communication
RS485, Modbus-RTU, 2-wire, up to 9600bps
IP Degree
Front: IP51
Operating Temperature
-10℃ ~ 55℃
Storage Temperature
-25℃ ~ 70℃
Relative Humidity
≤93%
Certificate
CE ISO9001,MID
Application

spec


DDS




Application


1608864229 1


■ Smart equipment

■ Intelligent building

■ Public facility

■ Industrial and mining enter enterprise

■ Panel Factory




FAQ

Elecnova Electric is committed to power monitoring, power quality improvement, electric safety products, and industrial automation products development since 1998. Our popular products are very diverse, such as: Multifunctional Power Meter, Active Harmonic Filter, Motor Controller and Power Management System, etc.
Our distribution network is spread to the major economy districts globally. Elecnova Electric and its distributors are delicate to provide high-quality power management solutions and in-time technical support to the local customers.


Q: Are you trading company or manufacturer ?
A: We are factory located in Jiangyin Jiangsu Province.


Q: Does your company provide customized manufacturing?

A: We provide OEM/ODM service to our customers. Our experienced R&D team will give our customer solution in a high efficiency way.

Q: How long is your delivery time?
A: 3-5 working days for the items were in stock, 15-21days for the items out of stock.

Q: Do you provide samples? Is it free or extra ?
A: You need to pay for the sample and cover the freight as well.

Q: What is your terms of payment ?
A: Order amount less than $3000, 100% paid before shipment, order amount more than $3000,30% as deposit, 70% before shipment, or by negotiated for the both parties.
