Product Application
SZP-6 series vibration sensor are mainly designed for industrial, commercial and general building vibration detection and control.It is suitable for various kinds of large and medium-sized rotating machinery and moving equipment such as fans, water pumps, reducers, bearing blocks, rolling friction bodies, etc. for direct measurement of vibration safety and temperature rise applications.
SPECIFICATIONS | ||
Sensitivity | 50mv/g | |
Acceleration range | ±100 g | |
Frequency Range (±10 %) | 0.5-5000Hz | |
Resolving power |
1mg
| |
Frequency response |
~15 kHz
| |
Transverse Sensitivity
|
≤5%
| |
Overload Limit (Shock)
|
±1000g
| |
Temperature Range (Operating)
|
-40 ～+121 °C
| |
Excitation Voltage
| +18-+28 VDC | |
Exciting CurrentBias current | 2 - 10 mA | |
Output bias voltage |
11±1VDC
| |
Output Impedance
|
<100 Ω
| |
Sensitive parts
|
Ceramics, Shear
| |
Size
|
See diagram
| |
Weight
|
50g
| |
Housing Material
|
Titanium alloy
| |
Electrical Connector
|
φ5 Coaxial Jack/M6
| |
Output mode
|
3-M5
| |
