0.2mohm WSN5930 Beam Welding Shunt SMD Resistor

3 week ago

1 0 

Guangdong Kinwill Electronic Co., Ltd

4 month

Product details

Beam Welding Shunt SMD Resistor

Beam welded shunt chip resistor for current sensing, SMD mounted, ultra-low resistance

Features excellent stability and passes AEC-Q200 automotive-grade reliability testing.

Product Features:

Electron beam welding process and pure copper electrodes make it an ideal solution for current sensing applications.
Excellent product consistency, high reliability, superior stability, and strong pulse resistance.
Special welding process, all-metal structure, and surface pickling passivation treatment ensure strong weather resistance.
Extremely low thermoelectric potential.
Ultra-low parasitic inductance and fast response speed, suitable for high-frequency AC current detection.
Compliant with RoHS and other environmental requirements.
Customization of special specifications is available.

*Current Sense Resistor Solutions Provider

Specializing in resistance shunt product, including plastic-encapsulated resistors, bare chip e-beam welding alloy resistor, and composite alloy resistors; automotive-grade shunt resistor, high-power U-type shunts, and CUSTOMIZED shunts. These products find applications across diverse market sectors such as power supplies, BMS (Battery Management Systems), automotive electronics, smart home appliances, smart industrial equipment, power tools, inverters, and battery cell testing equipment.
