Features:
Rewinding of various adhesive tape, protective film, glazing film, release film, etc.

Specifications: Introduction of equipment:
Main transmission part: The slitting machine uses AC motor with inverter as material to transmit power, and the acceleration and deceleration are stable and fast. The tension inverter is used to control the AC motor conveying tension, and the torque is fully automatic rebound control when the winding tension changes in diameter.
Part of the winding machine: the rewinding method is the center and the surface, and the application can be freely selected when rewinding different materials. The rewinding gas pressure shaft is automatically inflated and deflated, and the rewinding is automatically changed after the rewinding is completed.
Motor control part: The operation interface of the slitter adopts an LCD touch screen, which can directly set various slitting or rewinding conditions and operating conditions on the screen. The control part uses a programmable controller for mechanical action control, and has a self-testing system. When the machine fails, it can diagnose the fault cause by itself.
Auxiliary discharge device: the material is rolled out through the auxiliary press wheel, which can make the material more orderly and reduce noise.
Auxiliary pulling device: material roll-out can be assisted by the motor to pull material, saving pulling time and reducing material loss.
Basic discharge form: connected discharge stand, easy to operate, small footprint.

Optional equipment:
1. Auxiliary feeding of raw materials: The rewinder adopts hydraulic power, which is suitable for workshops without driving, which can save manpower and shorten loading and unloading time.
2. Automatic labeling device: After reaching the set length, automatic deceleration labeling, speed up the production speed, the length can be freely set (the rubber face can be equipped with the model).
