JCS4-16MF Cutting Table-1
2 month ago
Features:
1. Three high-precision servo control systems: Servo feed system, servo dimensional control, servo automatic angle rotation
2. Main shaft & circular blade drive powered by three-phase motor with stepless variable frequency speed regulation and vector high-torque output.
3. Janpan Mitsubishi PLC control system with automatic fault detection.
4. 10" color touchscreen LCD display supporting 20 preset dimensional auto-switching modes.
5. Taiwan PMI high-precision linear ball guide rails & ball screws.
6. 3" Internal expansion cutting shaft (optional 1"/1.5"/2" cutting shaft).
7. New heavy-duty tail stock with pneumatic-controlled support, enhanced reliability/stability for heavier loads; Dual-cylinder high-thrust chuck ensures firmer clamping.
8. Full-coverage integrated lift-up safety hood (optional fully enclosed guard).
9. Integrated bilateral automatic blade sharpening device.
10. C5 single shaft large cutting machine:single shaft & single knife design ensures stability, precision and compactness for high-accuracy processing of special jumbo log roll materials.
Ergonomic control panel design for improved operability.
Main Technical Parameters
|
Machine width |
1.3M 1.6M |
|
Cutting precision |
±0.1mm |
|
Max. Blade O.D. |
450mm |
|
Max. Cutting Diameter |
400mm |
|
Min. Cutting width |
2mm |
|
Inner core I.D. |
1"-3" |
Detailed Description: The JANBO C4 Automatic Cutting Machine is equipped with advanced technology to ensure accurate and clean cuts for different types of adhesive tape rolls. It can handle various materials with ease, making it a valuable tool for packaging, manufacturing, and other industries. The single shaft design allows for easy operation, while the cutter converter machine provides flexibility for different cutting requirements. Whether you need to cut PVC tape, warning tape, masking tape, kraft paper, BOPP packing tape, PET tape, PE protective film, foam tape, double-sided tape, conductive cloth tape, or copper foil tape, this machine delivers consistent results every time.
Usage Scenarios: The JANBO C4 Automatic Cutting Machine is ideal for businesses that require precise and efficient cutting of adhesive tape rolls. It can be used in packaging facilities, manufacturing plants, printing companies, and other industries where accurate cutting is essential. With its versatility and reliability, this machine is a must-have for any business that deals with adhesive tapes on a regular basis.
