Fully Automatic Double-End Shell Insertion Machine | TYDC-F-B602
7 month ago
The Fully Automatic Dual-Head Shell Insertion Machine is an advanced automatic wire harness assembly machine designed for high-speed, precise connector processing. This dual-end connector assembly machine integrates wire cutting, stripping, terminal crimping, and shell insertion into one fully automated cycle.
Equipped with a four-lens CCD vision inspection system, the machine ensures accurate terminal positioning, precise shell insertion, and consistent production quality. This system improves production efficiency, reduces manual labor, and guarantees stable output.
This machine is widely used in industries such as automotive wire harness production, home appliances, electronic equipment, industrial control wiring, and medical devices. It supports both single-head and dual-head operation, making it suitable for various wire harness production requirements.
| Processing at end A | Wire stripping, insulation stripping, terminal crimping, and housing insertion |
| Processing at end B | Wire stripping, insulation stripping, terminal crimping, and housing insertion |
| Additional functions | Single or dual-head operation Flexible housing insertion position Fully automated connector assembly process |
| Equipment advantages | Fully automated double-ended connector assembly system High-speed dual-head housing insertion machine Integrates cutting, wire stripping, crimping, and insertion CCD vision inspection system for 100% quality control Independent dual-servo tool holder for precise wire stripping adjustment Crimping accuracy up to 0.02 mm Flexibly adaptable to various wire harnesses Three-axis guided insertion system for improved accuracy Flip-type defective product inspection system Equipped with a handheld teach pendant for easy operation |
| Core configuration | Control System: Inovance Servo Motor: Inovance Cylinder: Taiwan Airtech Fiber Optic Amplifier: Panasonic (Japan) Transmission Module: Yaohua (equipped with Taiwan HIWIN ball screw guide) |
| Application areas | Automotive wiring harness manufacturing, home appliance cable manufacturing, industrial control cabling, medical equipment cable assembly, electronic connector assembly |
| Customized services | We can provide customized wire harness processing solutions and non-standard automated equipment based on customers' product and production needs. |
Why Choose This Machine:
The dual-end shell insertion machine provides high efficiency, high precision, and stable performance for modern wire harness production lines. Its fully automated system reduces labor costs while improving production consistency and quality. With flexible configuration and intelligent inspection technology, this machine is ideal for large-scale wire harness manufacturing and connector assembly applications.
