Product details

LD-80 High Precision Cold Pilger Mill

No.	Description		Unit	Tube Cold Rolling Machine Model
				LD-80
1	Hollow size	Outside diameter	mm	φ45～100
		Wall thickness	mm	1.5~7
		Length	m	2~5
2	Tube size	Outside diameter	mm	φ40～90
		Wall thickness	mm	1.2~6
		Length	m	≤7.5
3	Max. elongation ratio of rolling			It depends on the material
4	Stroke rate of roller carriage		str./min.	50～90
5	Stroke length of roller carriage		mm	643
6	Length of hollow feed		mm	1～8
7	Rotating angle of hollow during feed		Deg.	42～57
8	Rotate-and-feed mechanism			Servos Or Direct current
9	Method of loading/unloading			Manual/Mechanical
10	Number of rollers			3
11	Center height of hollow		mm	750
12	Power of main motor		kw	75

Our company has been deeply involved in Cold Pilger Mill for nearly 40 years and is a professional R&D and manufacturer of precision pipe making equipment in China.

The company independently develops two series of cold-rolled pipe machines with more than 30 specifications, covering the production needs of small to medium and large diameter precision pipes:

Cold Pilger Mill LG: suitable for rolling medium and large-sized pipes, with high production efficiency and strong stability.

Cold Pilger Mill LD: Specializes in small-diameter, high-precision pipe rolling. It can produce ultra-thin-walled precision pipes with a diameter of Φ4–8mm and a wall thickness of 0.1–1.0mm. It has excellent roundness, surface finish, and mechanical properties.
