2 Pin Power Connector is standard contact layout codes for combo waterproof d connector. Both models share the same feature: 2 high‑current power terminals in a compact D‑shaped shell, dedicated to power transmission.
Contact layout: Single row 2‑pin
Core function: High‑current power transmission
Housing size: Standard D‑SUB 1DE/E
Bend angle: 90° right angle for PCB mounting
Ingress protection: IP67
1. Key Features: Right Angle Design + High Current + ip67 connector
90° Right Angle (Right‑Pin) Design
“Right‑angle” or “right‑pin” means the connector pins are bent at 90°, specially designed for PCB soldering.
Advantages:
Space‑saving: Mounted parallel to PCB, greatly reduces overall device height
Stable mounting: Strong mechanical connection to PCB after soldering, high vibration resistance
Easy maintenance: Panel‑mounted design allows external plugging without opening the enclosure
High Current Capacity
Ip67 Connector 2v2 Male are designed for power transmission with flexible current ratings:
10A: Small equipment power, mixed signal & power transmission
20A: Industrial controller power, outdoor device power supply
30A: AGV charging ports, servo motor power cables
40A: New energy equipment, high‑power power input
Contact resistance can be as low as below 4 mΩ, ensuring low heat generation and high efficiency during high‑current transmission.
IP67 Waterproof & Dustproof
With precision sealing, the d connector achieves IP67 protection:
Fully dustproof: Suitable for mining, construction and other dusty environments
Temporary water immersion: Operable after immersion in 1m deep water for 30 minutes
Implementation:
Silicone sealing gaskets at the interface (some use red gaskets for identification)
Interface sealing technology
PBT insulation material with ultrasonic welding
Two Termination Methods
Wire‑solder type (cable mounting): Wires soldered to the connector rear, suitable for harness assembly and on‑site repair
Right‑angle PCB‑mount type: 90° pins soldered directly to the circuit board as a fixed device interface
Dongguan Pandi Electronics Technology Co., Ltd. is a primary manufacturer of waterproof connectors, with an history of 18 years.The current waterproof connector is a key product developed and manufactured by Pan Di. It has a waterproof rating of IP67, a low resistance value, and a long lifespan.
2. Specifications
Item Typical Value
Contact layout 2 Pin Power Connector
Rated current 10A / 20A / 30A / 40A (optional)
Rated voltage 125V ~ 300V
Ingress protection IP67
Contact resistance ≤4 mΩ ~ 10 mΩ (depending on current rating)
Insulation resistance ≥1000 MΩ ~ 5000 MΩ
Dielectric withstanding voltage 1000V AC / 1min
Operating temperature -55℃ ~ +125℃
Insulation material PBT + 30% glass fiber (UL94 V‑0 flame retardant)
Contact material Brass / pure copper, gold‑plated
Housing material Aluminum alloy / cold‑rolled steel with nickel plating
Mechanical life 500 mating cycles
3. 2V2 vs 2W2 Selection Comparison
Item 2V2 2W2
Pin arrangement Vertical arrangement Horizontal arrangement
Suitable PCB layout Better for vertical wiring Better for horizontal wiring
Space occupation Narrow width, moderate height Slightly wider width, lower height
Typical applications Compact devices, limited vertical space Slim devices, sufficient horizontal space
Selection Guide
For limited vertical PCB space: Choose 2W2
For limited horizontal PCB space: Choose 2V2
