55-inch smart conference tablet
2 year ago
Product details
Smart conference board makes conference work easier
Traditional digital whiteboards use switches or touch interfaces to turn on the display for interaction.
The smart conference board can directly turn on the whiteboard through voice control. In addition, it can also turn on the ops computer, voice control, music playback voice control channel switching, etc.
Product model number: M 5500E-D
Touch control mode: infrared multi-touch control
Backlight type: DLED
Product type: 982 solution conference all-in-one machine
Technical Review: Quality check: tabulation: Approval:
Touch control mode: infrared multi-touch control
Backlight type: DLED
Product type: 982 solution conference all-in-one machine
Technical Review: Quality check: tabulation: Approval:
|
Product Function
|
|
| wisdom ability language sound accuse make exploit ability | Voice control, turn on the whiteboard |
| Voice control turns on the OPS computer | |
| Voice control, and the play of the music | |
| Voice control switches the input channel | |
| Voice control to watch TV, switch channels, etc | |
| Voice control play weather forecast | |
| Voice-controlled Internet search | |
| Voice controls the volume | |
| Touch feel exploit ability | Support for 20-point computer touch operation |
| Support for image amplification,reduction,and rotation | |
| After supporting the switching of each signal source, the touch function is available | |
| Under the state when each signal source is displayed, control the signal source, volume and other menus by touch | |
| Complete machine characteristics | |
| Surface | Aluminum alloy face frame corner block design, front button, front port, front horn |
| Form size of the whole machine | 1277.8mm *782.8mm*97.4mm |
| Wall hanging hole size | 400*300m |
| Packing measurement | |
| Maximum power consumption rate | 100W (excluding computer), the standard computer power is 60W, the whole machine is 160W |
| Standby power | ≤0.5 |
| Working voltage | （AC）200-265V |
| Power interface | 1 road National standard prefix power interface input support |
| Working voltage | AC100V-240V 50/60HZ |
| Standby power consumption | 0.5W |
| The weight of the machine | |
| Service environment | Temperature-20℃ ~60℃ / humidity 10% RH ~ 90% RH |
| Storage environment | Temperature-10℃ ~55 degrees 10% RH ~ 90% RH |
| Display specifications | New original TFT-LCD A + LCD screen |
| Display size | 55 in. (16:9) |
| Display type | LED LCD display screen |
| Displays the size | 1210(H) x 680(V) |
| Physical resolution | 3840（H）×2160（V） |
| Show color | 10bit, 1.07B |
| Refresh rate | 60HZ |
| Luminance | 350cd/m2 |
| Contrast ratio | 1200：1 |
| Perspective (degree) | 178° |
| Display protection | 4mm, fully tempered, anti-glare and explosion-proof glass |
| Backlight life | For 50,000 hours |
| Android system parameters | |
| Chip | T982 |
| CPU | The ARMCortex-A53 quad-core, with the main frequency of up to 1.5G |
| GPU | Mali-G52 MP2(2EE) |
| Run memory | 4G DDR |
| Store memory | 32G EMMC |
| Operating system | The Android 11.0 operating system |
| OSD language | Simplified Chinese, English, etc |
| Analog video | CVBS 1.0Vp-p + / -5% |
| Multi-media | Video: MPEG-1 / 2 / 4, AVS2 MP, H.264,H265,VP9 Audio: MP3, AAC, WMA, RM, FLAC |
| High-definition video | 480i / 480p / 576i / 576p / 720p / 1080i / 1080p / 2160p |
| Network | 2.4G wireless network, wired network, Bluetooth |
| Horn specifications | 10W / 8 O. 2 speakers |
| Port | RG 45 input network port (Ethernet): 1 out |
| AVIN: 1 out of them | |
| AV OUT: 1 out of each | |
| RS232:1 with DB9 | |
| Headphone output Earphone: 1 piece | |
| HDMI signal input port: 4 | |
| TOUCH Output: 1 out of the output | |
| SPDIF: 1 out | |
| Android USB2.0:3 (rear 1, front share 2), USB3.0:1 | |
| WiFi | 1x 2.4G built-in module,1x 5G built-in module |
| Touch parameters | |
| Structure mode | Embedded built-in integrated, non-external type |
| Touch technology | Multi-point infrared touch technology (20 points) the high precision is 46 points |
| The way of writing | Finger, touch pen, or other non-transparent objects not less than 5mm in diameter |
| Cursor speed | At 120 points / s |
| Positioning accuracy | Over 90% of the touch area is ± 2mm |
| Communication interface | Type B USB header |
| Touch resolution | 32767*32767 |
| Touch times | Theory infinite times |
| Computer response | System automatic recognition; 15ms |
| Drivers | Free drive |
| OPS computer interface parameters | |
| CPU | I3 \ I5 \ I7 is optional |
| Internal storage | 4G\8G\16Gapolegamy |
| Hard disk | 128 \ 256G \ 512 Optional |
| USB | USB2.0*4 USB3.0*2 |
| LAN | 1 |
| HDMI | 1 |
| MIC | 1 |
| AUDIO | 1 |
| PC POWER | 1 |
| One-button restore / RESET key | 1 |
Jiangsu Qilong Electronic Technology Co.,LTD.is a factory located in China. Specialized in producing Education Interactive Board, such as Interactive conference board, Memory blackboard, Smart blackboard,Training Interactive Board，etc.
