65-inch conference all-in-one machine
2 year ago
Product details
SMART Board E70 interactive flat panel display: Let classroom interaction return to real touch
One screen to meet the basic needs of teaching: the golden combination of touch and software
This 70-inch large screen combines smooth touch and SMART Notebook software perfectly - just like the tacit understanding between chalk and blackboard, except that now you can write and draw on the screen with your fingers, and you can also pull students to circle key points and drag the board on the courseware. The courseware is stored in the cloud and can be retrieved at any time. The classroom interaction has changed from "one-way output" to "multi-person competition".
Visible high-definition, tangible smoothness
The 177.8 cm LED large screen has no shadow: the courseware is not white or blurred when projected, even the small words in the PPT are clear, and the students in the back row can see the blackboard clearly without squinting.
The glass screen is as smooth as silk
the fingertips move smoothly on the screen, the blackboard writing is not stuck, and the fingers are pinched and released when zooming in and out of the picture, which is less "dragging" than the traditional touch screen.
No matter where you sit, you won't be dazzled: the screen has been treated with anti-glare, so even if there is sunlight coming in from the window, the words will not "hide and seek". From the podium to the last row of the classroom, it is as comfortable to look at the screen as to look at the textbook.
Multiple people on the same screen play new teaching tricks
The most interesting thing is that it allows several people to toss on the screen at the same time - the teacher marks the knowledge points on the left, the students drag the formulas on the right, and during the group discussion, they directly draw mind maps around the screen, and every stroke is synchronized in real time. There is no need to squeeze in front of the podium to look at the small blackboard. Classroom interaction should be so lively.
Classroom artifact that spends money on the blade
In terms of practicality, high-definition screen + non-slip touch + multi-person collaboration are all included; in terms of peace of mind, the anti-glare design does not require the curtains to be drawn all the time, and the software functions can be used for daily teaching. There are no extra gimmicks, it is a thing that really makes the classroom more efficient. No wonder many schools use it as the main teaching force.
Jiangsu Qilong Electronic Technology Co.,LTD.is a factory located in China. Specialized in producing Education Interactive Board, such as Interactive conference board, Memory blackboard, Smart blackboard,Training Interactive Board，etc.
Product parameter description
|
The 65-inch parameter specification |
||
| Size | 65'' | |
| Naked machine size | 1488.4m m * 892 m m*91.55m m (excluding the hanger) | |
| Packing measurement | 1600mm * 1030mm * 200mm (heavy duty carton) | |
| Display area | 1430(H)×804(V)mm | |
| Dot pitch | 0.124×0.372 mm (H×V) | |
| Optimum resolution | 3840x 2160 | |
| Luminance | 350cd/㎡ | |
| Contrast ratio | 4000：1（Typ.) transmission | |
| Visual Angle | 178°,178° | |
| Response time | 6.5ms | |
| Show color | 8 bit/16.7 Billion | |
| Backlight | DLED | |
| Screen life | 50000 Hours | |
| Power | ≦260W | |
| Working voltage | 100V-240VAC,50/60Hz | |
| Loudspeaker | 8Ω10W*2 | |
| Net weight / gross weight | Estimated 38Kg±1.5Kg / 45Kg±1.5Kg (heavy-duty carton) | |
| Android system parameters | CPU | With a high-performance Quad core ARM Cortex-A55 architecture |
| GPU | High efficient ARM Mali-G52 MP2 (2 EE) GPU | |
| RAM | 4G | |
| FLASH | 32G | |
| Android version | Android 11 | |
| OSD language | Chinese (Simplified) Traditional Chinese Spanish Korean Portuguese Italian-Italy Russian English |
|
| I/O joggle | The 1 * TOUCH OUT port The 2 * USB2.0 port The 1 * MICRO SD port The 2 * HDMI port The 1 * COAX port The 1 * AV IN port The 1 * AV-OUT port The 1 * RS232 port The 1 * RJ 45 port The 3 * WIFI antenna |
|
| CPU | Intel I3 / I5 / I7 (optional) | |
| Video card | Intel CPU integrated graphics card | |
| Ops parameter | Internal storage | 4G DDR3 / DDR 4 (Optional) |
| Caliche | SSD:128G /120G | |
| network card | Realtek 8111F Gigabit network card | |
| I/O joggle | The2 * USB2.0 port The 2 * USB3.0 port The 1 * is the VGA port The 1 * COM port The 1 * HDMI port The 1 * RJ 45 port The 1 * WIFI antenna The 1 * Earphone-OUT port The1 * MIC-IN port The 1 * POWER button is pressed |
|
| System | Support for Windows 7 / Windows10 | |
| Infrared touch configuration | Resolution ratio | 32768（E)*32768(D) |
| Touch point number | WIN 7 (flagship) drive 10, Android driver 6 / 10 | |
| Touch accuracy | ±2mm | |
| Response time | 4ms~12ms | |
| Recognizable object | Φ 5mm, with a non-transparent object | |
| Light transmittance | 90% of the tempered glass | |
| Temperature range | Operating temperature: 0℃ ~60℃ | |
| Working voltage | DC5V | |
| Work power consumption | ≥1W |
