65 inch quadrilateral infrared touch
2 year ago
| Product Parameter | |
| Panel type | Original A + level commercial LCD panel |
| display resolution | 1920*1080 |
| Panel size | 65-inch (16:9) |
| Backlit type | E-LED |
| Valid display area | 1428*803 |
| Color degree | 8bit，1.07B |
| Luminance | 300-350 cd/㎡ |
| Contrast ratio | 1200：1（Typ.） |
| Visual Angle | 178°（H ）/178°(V) |
| Backlight life | For> 35,000 hours each |
| Horn | 2×4Ω 10W |
| HDMI-OUT | 1 |
| VGA-OUT | 1 |
| RG45-IN | 1 |
| USB3.0 | 2 |
| USB2.0 | 2 |
| Audio output | 1 |
| Headphone input | 1 |
| The 220v socket interface | 1 |
| WIFI | 1 |
| Touch parameters | |
| Touch-embedded mode | Built-in one-piece |
| The way of writing | Finger, touch pen, or other> 2.5mm |
| Number of touch points | At 10 o'clock |
| Touch resolution | 32767*32767 |
| Touch precision | ±1mm |
| Single refers to the response speed | ＜8ms |
| Minimum identification point diameter | 2.5mm (support 2.8mm double fine pen full screen writing) |
| Touch number | The theoretical number is infinite |
| Drivers | System automatic identification, no drive |
| Support system | windows7/10，Android，Mac OS |
| working temperature | -10~+50 ℃ |
| Computer parameters | |
| Motherboard | Industrial industrial control motherboard |
| CPU | The Intel-i5-4200M cpu is optional |
| Internal storage | The Ddr 3-4G is optional |
| Hard disk | The SSd-128G is optional |
| WiFi | 2.4G/5G |
| Body material | Aluminum alloy drawing wire oxidation face frame treatment process |
| Front frame glass | Physical tempered grade 7 explosion-proof glass |
| Appearance size of the whole machine | 1267.8 * 728.6 * 61.7 (excluding wall hanging) |
| The power of the machine | ≤150W |
| Standby power | ≤0.5W |
| Sound horn | Stereo sound effects, 2 * 10W high and height sound |
| Input voltage | 100~240V 50/60Hz |
| Service environment | Temperature-20℃ ~60℃ / humidity 10% RH ~ 90% RH |
| Storage environment | Temperature-10℃ ~55℃ / humidity 10% RH ~ 90% RH |
| packing measurement (mm) | |
| Product weight | |
| way to install | Wall hanging, with the base of the horizontal type, etc |
| Packaging accessories | power line |
| telecontroller | |
| WiFi antenna | |
| Wall hanging bracket | |
| Certificate |
