Product details

High-performance scene-based interactive tool with infrared touch screen integrated machine with graphics card

Designed for product showrooms, conference rooms, design companies and research institutes, it integrates high performance and strong expandability, and can easily handle high-load scenes such as VR/AR, 3D display and large-scale design software.

Core advantages

Free expansion, strong performance

Supports any graphics card built-in, flexible adaptation to different computing power requirements; low noise design ensures stable operation and meets high-performance applications in multiple scenarios.

Sensitive touch, high cost performance

10-point infrared touch technology, sensitive response, smooth operation; achieve professional-level interactive experience at an affordable price.

All-platform interconnection

Native support for Windows system, built-in 2.4G/5GHz dual-band WiFi and Bluetooth, efficient and stable wireless transmission; rich interfaces such as USB3.0, HDMI2.0, DP, etc., easy external devices, and multi-screen collaboration.

From immersive VR experience display to complex design project collaboration, this all-in-one machine has become the core equipment for efficient interaction and creative implementation with its flexible configuration and excellent performance.

Jiangsu Qilong Electronic Technology Co.,LTD.is a factory located in China. Specialized in producing Education Interactive Board, such as Interactive conference board, Memory blackboard, Smart blackboard,Training Interactive Board，etc.

Product Parameter
Panel type	Original A + level commercial LCD panel
display resolution	1920*1080
Panel size	65-inch (16:9)
Backlit type	E-LED
Valid display area	1428*803
Color degree	8bit，1.07B
Luminance	300-350 cd/㎡
Contrast ratio	1200：1（Typ.）
Visual Angle	178°（H ）/178°(V)

Backlight life	For> 35,000 hours each
Horn	2×4Ω 10W
HDMI-OUT	1
VGA-OUT	1
RG45-IN	1
USB3.0	2
USB2.0	2
Audio output	1
Headphone input	1
The 220v socket interface	1

WIFI

Touch parameters
Touch-embedded mode	Built-in one-piece
The way of writing	Finger, touch pen, or other> 2.5mm
Number of touch points	At 10 o'clock
Touch resolution	32767*32767
Touch precision	±1mm
Single refers to the response speed	＜8ms
Minimum identification point diameter	2.5mm (support 2.8mm double fine pen full screen writing)
Touch number	The theoretical number is infinite
Drivers	System automatic identification, no drive

Support system	windows7/10，Android，Mac OS
working temperature	-10~+50 ℃

Computer parameters
Motherboard	Industrial industrial control motherboard
CPU	The Intel-i5-4200M cpu is optional
Internal storage	The Ddr 3-4G is optional
Hard disk	The SSd-128G is optional
WiFi	2.4G/5G
Body material	Aluminum alloy drawing wire oxidation face frame treatment process
Front frame glass	Physical tempered grade 7 explosion-proof glass
Appearance size of the whole machine	1267.8 * 728.6 * 61.7 (excluding wall hanging)
The power of the machine	≤150W

Standby power	≤0.5W
Sound horn	Stereo sound effects, 2 * 10W high and height sound
Input voltage	100~240V 50/60Hz
Service environment	Temperature-20℃ ~60℃ / humidity 10% RH ~ 90% RH
Storage environment	Temperature-10℃ ~55℃ / humidity 10% RH ~ 90% RH
packing measurement (mm)
Product weight
way to install	Wall hanging, with the base of the horizontal type, etc
Packaging accessories	power line
	telecontroller
	WiFi antenna
	Wall hanging bracket
	Certificate

Display:

65-inch equilateral infrared touch all-in-one machine
