A04 Series OPS computer

13 month ago

7 0 

Jiangsu Qilong Electronic Technology Co., Ltd.

2 year

Product details

Core features

Standardized open architecture

Based on the VESA OPS standard interface, the computing module is decoupled from the display device, and supports inter-plugging of hardware of different brands (such as Intel/AMD processor modules adapted to large screens of various brands).

Supports hot-swap maintenance, and the computing module can be replaced without disassembling the entire machine, which improves maintenance efficiency by 50%.

Modular and flexible configuration

The independent computing module (including CPU/memory/storage) is separated from the display module. Users can upgrade computing performance as needed (such as upgrading from Celeron to Core i7), or replace the display device without eliminating the host.

High performance and reliability

Equipped with the latest processor (such as Intel 12th generation Core) and graphics card, it supports 4K/8K video processing and multi-tasking.

Industrial-grade design supports 7×24 hours of uninterrupted operation, suitable for conferences, teaching, industrial control and other scenarios.

Strong scalability and integration

Supports multi-interface expansion such as HDMI/USB/network port, and is adapted to external cameras, touch screens, printers and other devices.

Easy to integrate with existing systems (such as whiteboard software, conference system) to reduce deployment costs.

Security and environmental adaptability

Integrated hardware encryption and firewall functions to protect data security.

Wide temperature design (-10℃~50℃), adaptable to complex environments such as business, medical, and industry.

Application scenarios

Education/Conference: Large-screen touch all-in-one machine with OPS module, supports dual system (Windows+Android) switching and teaching software operation.

Industrial control: Modular design facilitates integration of touch display and data processing functions in production lines.

Commercial display: Advertising machines and self-service terminals upgrade computing power through OPS modules to support dynamic content rendering.

Processor	System Chipset	Intel®H110-CExpress
Processor	CPU Model	I3/I5/I7 6th to 9th generation desktop CPU
Memory	Technology	1 x SODIMMs DDR4
Memory	Memory	DDR4-4G;DDR4-8G;DDR4-16G;
Display	Front End Output	DP-Max.3840 x 2160@60Hz HDMI-Max.3840 x 2160@30Hz
Display	JAE End	HDMI-Max.3840 x 2160@60Hz
Processor graphics card	Model	CPU integrated graphics
Hard Disk	SSD	MINI-SATA Solid State Hard Disk Interface 128G；256G；512G；1T-Optional
WIFI	Interface	M.2 PCIe
WIFI	Support	Ailian-2.4G/5g dual frequency
I/O Interface	JAE Connector	1(JAE TX25 80-PIN)
	LAN	1x10/100/1000Mbps(RJ45)
	USB	3USB3.0 & 3USB2.0
	Audio frequency	1 x AUDIO OUT + 1 x MIN IN
Power requirements	Input voltage	DC-IN 12-19V wide voltage, 90W overall power.
Physical characteristics	Size	180x 195x 30MM （180x 195x 42MM-Optional）
Physical characteristics	Shell material	Iron sheet
Dissipate heat	Cooling mode	All aluminum double fan
Environmental	Working temperature	-20℃~60℃
Environmental	Relative humidity	10% - 90℃(non-condensing)
Sdk	Operating system	Windows®7 Windows®10

Jiangsu Qilong Electronic Technology Co.,LTD.is a factory located in China. Specialized in producing Education Interactive Board, such as Interactive conference board, Memory blackboard, Smart blackboard,Training Interactive Board，etc.
