Brass Press Briquettes Making Machine Metal Press

Brass chip cake machine is a kind of equipment that processes brass chips into cakes through pressure. It is mainly used in brass processing and recycling industries to compact loose brass chips for storage, transportation and subsequent smelting and other processing operations.

Working principle:

The equipment mainly provides strong pressure through hydraulic system or mechanical pressure system. When the brass chips are placed in the material chamber of the machine, the pressure system starts and squeezes the brass chips through the pressure head or piston. The hydraulic system works by using a hydraulic pump to pressurize the hydraulic oil, and then delivers the high-pressure oil to the hydraulic cylinder to drive the piston to move and generate pressure;

The mechanical pressure system usually drives the mechanical structure such as the screw or crankshaft through a motor to convert the rotational motion into linear motion, thereby generating pressure. Under the action of pressure, the gaps between the particles of the brass chips gradually decrease, and are finally pressed into a tight cake shape.

Advantages:

1. Improve storage and transportation efficiency Metal Briquetting Press

Brass shavings are originally loose and take up a lot of space. After being pressed by the cake machine, the volume is greatly reduced and the shape is regular. For example, unpressed brass shavings may be relatively fluffy when piled up, but after being pressed into a cake shape, the volume of brass shavings of the same mass may be only 1/3 - 1/5 of the original. This greatly improves the space utilization of the warehouse during storage; during transportation, more brass materials can be loaded, the number of transportations can be reduced, and the transportation cost can be reduced.Metal Press

2. Convenient for subsequent processing

Cake-shaped brass is more convenient in subsequent processing such as smelting. Compared with loose brass shavings, cakes can be better heated in the furnace, melt more evenly and quickly, and reduce smelting time and energy consumption. Moreover, the regular cake shape is convenient for mechanical devices to carry and put, which improves the degree of automation of processing.Hydraulic Briquetting Machine

3. Reduce environmental pollution

Loose brass shavings are easy to scatter during storage and transportation, which not only causes waste of materials, but also may pollute the environment. For example, brass scraps may be mixed into soil or water, causing heavy metal pollution. After the brass scraps are pressed into cakes, the risk of their scattering is reduced, which is beneficial to environmental protection.Metal Briguette Machine

Model	Inner dia.of main cylinder	Briquette size (mm)	Briquette density (T/m3)	Briquettes/min	Production (T/shift)	Power(kw)	Operational mode
Model	Inner dia.of main cylinder	Briquette size (mm)	Briquette density (T/m3)	Briquettes/min	Production (T/shift)	Power(kw)	Operational mode
Y83-2000	280	φ80×(60-80)	≥5	4~5	3~5.5	18.5	PLC automatically
Y83-2500	320	φ90×(60-80)	≥5	4~5	5~8	30
Y83-3150	360	(φ90~φ110)×(70-100)	≥5.5	4~5	5~8	30
Y83-3600	400	(φ100~φ120)×(70-100)	≥5	4~5	8~12	30
Y83-5000	450	(φ110-φ140)×(70-100)	≥5	4~5	10~14	37
Y83-6300	520	(φ130-φ160)×(70-100)	≥5	4~5	16~20	45
