Ip67 Cable Connector 4 pin:

Dongguan Pan Di Electronic Technology Co., Ltd. is a professional manufacturer of connectors, specializing in the development and production of d sub connectors and related products. The production process includes: lathe work, stamping, injection molding, electroplating assembly, and testing (6 industrial processes). The characteristics of Pan Di connectors include stable output, strong conductivity, low resistance, and long lifespan. Waterproof connectors are a high-quality product that Pan Di has focused on developing and manufacturing.

This D Sub Power Connector 4 pin is a highly favored product among customers within the Pan Di range. The rated current is 10-40A (customization is available).

Product Features: Stable output, strong conductivity, low resistance, long service life

Packaging: Blister packaging / outer carton

Environmental Compliance: Meets EU environmental requirements

Brand: pandi

Applications: Engineering medical equipment, 5G communication networks, aviation, automotive new energy manufacturing & transportation, energy storage, wiring harnesses, 5M7 SMT, laser equipment, and other fields

The parameters of this d connector:

Parameter: Specification

Contact Layout : 4W4 (4 High-Current Coaxial/Power Contacts)

Protection Rating : IP67(ip67 d sub)

Rated Current : 10A / 20A / 30A / 40A (Customizable)

Rated Voltage: 250V

Contact Resistance: ≤15mΩ

Insulation Resistance: ≥2000MΩ

Dielectric Withstand Voltage： 750V AC / 1min

Operating Temperature： -55°C ~ +105°C

Contact Material： Brass / Pure Copper, Gold Plated

Insulator Material： PBT + 30% Glass Fiber (UL94 V-0)

Shell Material： Aluminum Alloy / Cold Rolled Steel (Nickel Plated)

Mechanical Durability： ≥1000 Mating Cycles

Locking Mechanism： Threaded Locking (Jackscrews)
