Self Operated Pressure Reducing Regulating Valve

4 week ago

5 0 

Hangzhou Baoheng Valve Manufacturing Co., Ltd.

3 month

Product details

The Self Operated Pressure Reducing Regulating Valve is a comprehensive series offering multiple size variants within a single product family, all sharing the same robust pressure‑reducing principle. This valve requires no external energy, relying on a spring‑loaded diaphragm or piston to maintain a constant downstream pressure regardless of upstream fluctuations. It is particularly suited for steam, compressed air, and inert gas services where simplicity and reliability are paramount. The series covers outlet pressure ranges from 0.05 to 1.6 MPa, with adjustment possible via a handwheel or locking nut. The body materials include cast iron, ductile iron, and carbon steel, with stainless steel internals for corrosion resistance. These regulators are widely deployed in district heating plants, steam tracing systems, and industrial air networks. They serve as the primary Pressure Control Valve for reducing high‑pressure steam to usable levels, while also complementing a Temperature Regulating Valve in heat exchangers to maintain precise outlet temperatures. Because they are Self‑operated Valve designs, they eliminate the need for instrument air compressors, reducing capital and energy costs. Their straightforward internal design – with replaceable seats, plugs, and diaphragms – allows quick overhaul without specialized tools. The multiple sizes provide flexibility for engineers to select the optimal Cv value, ensuring stable control without oversizing. Optional features include internal or external pressure taps, balanced plugs for high inlet pressures, and soft seats for bubble‑tight shut‑off. When combined with a pressure transmitter, the valve can be monitored remotely, effectively becoming part of an Intelligent Control Valve monitoring network for predictive maintenance. Its fail‑safe characteristic – closing upon spring failure – ensures safety in critical heating applications. All units are factory‑set and tested per ASME standards, with certification available upon request. This valve family is a cost‑effective solution for plants that require multiple pressure reducing stations with minimal spare parts inventory, as all sizes share common diaphragm and seal kits.
