SP4-616CPSK shuttle servo pad printer

2 year ago

92 0 

10 year

Product details

Samples

This four-color intelligent servo shuttle pad printing machine is a premium solution designed for demanding and high-precision printing applications. The machine frame is constructed from high-strength cast iron, providing exceptional rigidity, vibration resistance, and long-term stability for continuous production.

The servo-driven shuttle table enables accurate position transfer between different printing stations, delivering multi-color registration accuracy of up to ±0.03 mm. Each closed ink cup is independently driven, ensuring clean ink doctoring while minimizing ink evaporation and maintaining a stable printing environment.

The machine features an independent pad printing system with separate adjustment mechanisms for ink pickup, transfer, and printing movements. This design guarantees consistent printing quality and highly repeatable positioning throughout the production process. Through the intuitive HMI interface, major printing parameters can be digitally adjusted with millimeter-level precision, making the machine ideal for complex and demanding printing tasks.

Built on a modular platform, the machine can be integrated with plasma treatment systems, laser marking units, and robotic loading and unloading devices to achieve higher levels of automation. With intelligent controls and user-oriented programming, this machine provides outstanding flexibility, precision, and reliability for advanced pad printing applications.

Description

4 colors closed cup pad printer with shuttle//Parameter
Technical parameters	SP4-612CPSK
	Max. plate size: 150×300 mm; Max. worktable area: 200×125mm; Max. printing area:130×130mm; Max. printing speed: 550pcs/h; Printable colour :4; Shuttle stroke: 200mm; Max product dimension: 300×260mm
	SP4-614CPSK	SP4-616CPSK
	Max. plate size: 150×350 mm; Max. worktable area: 200×125mm; Max. printing area:130×170mm; Max. printing speed: 550pcs/h; Printable colour :4; Shuttle stroke: 200mm; Max product dimension: 300×260mm.	Max. plate size: 150×400 mm; Max. worktable area: 200×125mm; Max. printing area:130×220mm; Max. printing speed: 550pcs/h; Printable colour :4; Shuttle stroke: 200mm; Max product dimension: 330×260mm.
Works supply	110V-220VPower supply; 5-7Bar Compress air;
Package list	Package dimension:1.050×0.990×1.460M Gross weight: 260kg; CBM: 1.5177
H.S.Code	8443198000
Certicate	CE

Details

Key Features
- Microcomputer-Controlled Operating System
- Streamlined Design with Modern Appearance
- Heavy-Duty Aluminum Alloy Frame Construction
- Servo Shuttle Table for Precise Color Registration
- Independent Pad Pressure and Ink Pickup Adjustment
- Test Mode and Production Mode Operation
- Open Ink Tray System for Easy Ink Adjustment
- Automatic Digital Production Counter
- Four-Color Printing with Hot Air Intermediate Drying
- Ten-Level Adjustable Printing Speed
- Automatic, Semi-Automatic, and Test Operation Modes
- Self-Balancing Doctor Blade System for Clean Ink Transfer
- Enlarged Ink Tray for Large Image Printing
- Stable Multi-Color Overprinting Performance
- User-Friendly Setup and Operation
- Ideal for Large-Format Multi-Color Printing Applications

What configurations do high-end four-color shuttle pad printers generally have?

There are many types of pad printers on the market, and the prices vary greatly. So what characteristics do high-end four-color shuttle pad printers generally have?

Control system

The operation panel will be controlled by a microcomputer or a more advanced PLC equipped with a human-machine interface.

Power system

The shuttle of the workbench, the lifting and lowering of the pad printing rubber head, the rotation of the rubber head cleaning device, and the sliding of the oil cup, if these actions are controlled by servo motors, the power of the pad printer will be more stable and accurate.

Brand components:

Pneumatic components and electronic components use domestic or international diameter brands such as AIRTAC, FESTO or Japan SMC, etc., and the life of the pad printer will be longer.

Printing system

The movement of the rubber head of the four-color shuttle pad printer is becoming more and more complicated. For example, the downward printing stroke is larger, which is suitable for printing concave products. In addition to the downward movement, the rubber head can also rotate at any angle, which is suitable for any complex products.

Drying system

Equipped with hot air device or UV curing device, it can achieve rapid drying of ink, and can also be combined with laser marking machine for etching pad printing.

High-precision workbench:

The workbench adopts a high-precision base, X, Y, and R can be adjusted independently, and is equipped with precision cross guides.
