Aromatherapy Machine Atomizer Plate

2 month ago

7 0 

Shenzhen Liandaqi Precision Ceramic Co., Ltd.

3 month

Product details

This Φ13.8mm microporous atomizer is a high-performance core component designed for aromatherapy machines, small fans and air coolers. It uses 316L stainless steel and precision piezoelectric ceramic composite technology, equipped with 600 7μm micropores, which can achieve efficient atomization effect and is an ideal choice for 5V Ceramic Disc For Aromatherapy applications.

Atomization Disc Product Specifications

Metal sheet: Φ13.8±0.1mm
Piezoelectric sheet: Φ11.3±0.2mm
Hole area: Φ2.5±0.2mm
Hole diameter: 7±1um
Number of holes: 600 holes precisely arranged
1571#28 double red line: L=60±5mm
Diameter of rubber ring: 15±0.5mm
Bare chip thickness: 0.65±0.1mm
Thickness of rubber ring: 2.5±0.3mm

Atomizer Plate Features

600 micropore design: pore size is only 7±1μm, the atomized particles are fine and uniform
High-efficiency atomization area: 2.5mm diameter perforated area, atomization efficiency increased by 30%
5V low voltage compatibility: adapt to a variety of aromatherapy machines and small fan power supply systems
Resonant frequency: 150±10KHz, atomization is stable and noiseless
Low impedance design: ≤500Ω, energy consumption is reduced by 20%
Long life: more than 3000 hours of continuous working life

5v Ceramic Disc For Aromatherapy Industry Applications

Essential oil atomization diffusion
Indoor humidity control
Medical atomization treatment
Water mist cooling system
Car cooling device
Desktop microclimate control

Conventional microporous atomizer parameters

Atomizer window cleaning atomizer plate supply
