J-Tron focuses on the design and production of Micro Gear Pump, Mini Solenoid Valve, and Liquid Control Component. Just share your technical specifications, operating conditions, and assembly dimensions with us. We provide customized service. Our expert team will tailored solutions and craft product designs that align perfectly with your requirements.

PRODUCT DISCRIPTION: Magnetically-Driven Medical Gear Pump

J-Tron’s Magnetically-Driven Medical Gear Pump--GPM Series is specially engineered for diagnostic and hemodialysis devices. It features a cavity style design, with no dynamic seals for applications that cannot tolerate leak. It adopts SS316L pump body, PEEK gears, and SS316L or ceramic shafts. Boasting corrosion resistance, accurate dosing, low-pulsation flow, minimal noise, excellent self-priming ability, and customizable setups, GPM Series can operate smoothly even in demanding application scenarios.

KEY FEATURES
*Hermetically sealed

*Chemically resistant

*Long service life

*Brushless motor

MAIN APPLICATION

*Dialysis & IVD

*Medical devices

SPECIFICATION: Magnetically-Driven Medical Gear Pump

Technical Parameter
Portfolio	GPM3500
Flow Rate	3.5L at 5400RPM
Displacement	0.64ml/Rev
Suction	2Meter
Max Differential Pressure	8Bar
Revolution Range	100~5400RPM
Viscosity Range	0.5~1500cps
Connection	TNP1/8
Material
Pump Body	SS316
Gear	PEEK
Shaft	SS316/ Ceramic
Magnets	Rare Earth
Brushless Motor
Voltage	24V DC
Drive Control	0~5V DC & PWM 0-100%
Power Consumption	40W/70W
