Product details

Product Description
J-Tron precision flow mini 316L magnetic pump is the kind of water pump with small size and low flow. This high-performance SS316L gear pump has 3 flow rate options that you can choose and corresponding pressure: ①flow rate of 1.6L/min with 20bar; ②flow rate of 3.5L/min with 8bar; ③flow rate of 6L/min with 7bar. To guarantee the performance, we develop our own motor to match our pump which is brushless motor 40W/70W. For this mini 316L magnetic drive gear pump, it is the cavity design with a pair of modified PEEK gears. The over all pump body stainless steel 316L. Thanks to the PTFE sealings our pump has excellent seal performance.

Advantage

Thanks to the advanced materials used, there are no expansion, distortion, abrasion, or corrosion happens. Our stainless steel micro metering gear pump passes life test for more than 30,000 hours service life. What's more, our micro gear pump is NSF certified to guarantee the food safety.

Application

J-Tron 24V DC gear pump is the compact gear pump solution for coffee machine, juice dispensing, beer brew, tea extract, and other sepcific food and beverage segments.
