Product details
Dielectric coating mirror is an optical component that achieves high reflection by alternative depositing multiple layers of media films with different refractive indices on a substrate. Unlike traditional metal reflectors( such as aluminum mirrors or silver mirrors), it does not reply on the plasma effect of metals, but instead utilizes the principle of light interence.
Mainly principle: optical interference
Basic structure: usually two types of optical materials( one with high refractive index nH and the other with low refractive index nL)are grown alternately, and the optical thickness of each layer is one quarter of the target wavelength.
Phase-matching interference: at the interface, the reflected light from each layer of the film has the same phase at a specific wavelength, and they add together, thereby significantly enhancing the total reflection rate.
Can be design bandwidth:by adjusting and the thickness and number of layer, the central wavelength and bandwith of high reflection can be precisely controlled.
Dielectric mirror film VS Metal reflective mirror
| Characteristics | Dielectric mirror coating | metal reflective mirror |
| Reflectivity | extremely high(>99.9%) approaching the theoretical limit | Relatively low( aluminum 92%, silver 98%) |
| Absorption/dissipation | extremely low, with scattering loss being the dominant factor | higher, with inherent absorption present |
| Laser damage threshold | very high, sitable for high power laser | low, prone t being burned |
| Designability | customizable wavelength, angle, polarization response | Fixed, wide-band response |
| Cost | Higher, with complex design and manufacturing | lower,easy to prepare |
| Typical Application | Laser cavity, precision optical system | General lighting, imaging, daily necessities |
CCRQ offer various types of mirror as following
*High Reflection Mirror: used in the laser resonator to provide feedback
*Low reflection coating/Anti-reflective film:reduce surface reflection and enhance transmission
*Beamsplitter: divides the incident light into two beams, one for reflection and the other for transmission in a specific ratio
*Dichroic mirror: Reflects/Transmits based on wavelength, such as the color splitting mirror used in fluorescence microscopes
Advantage of Dielectric mirror glass
*Extremely high reflectivity with extremely low absorption loss
*Extremely high laser damage threshold, suitable for high power application
*The performance is highly customizable( in terms of wavelength, angle, and polarization)
*The durability is good, superior to the easily oxidizable silver film
Our company specializing in processing, production and sales of precision optical components, we specialize in optical component including Sapphire Windows, Spherical Lens, Optical Mirrors Optical Windows, Optical Prisms, Filters and Lasers.
We have a skilled optical engineer team which is expertised in processing optical components for over 10 years and have a completed production line of cutting, milling, grinding, polishing, coating, spray paint, and assembly.
The superior quality of product and our best service enable us to cooperate with more and more customers domestically and overseas.
Our product categories are listed as follows.
1.Laser optics, such as Laser focus lens, laser mirror applicable to laser cutting and engraving machines ect
2.Infrared optics, such as Sapphire Window, CaF2 Window, BaF2 Window, MgF2 Window, ZnS window, Znse window, Silicon window, IRG205, IRG206, IRG207 ect
3.Optical glass components, such as Spherical Lens, achromatic lenses doublet, ball lens, collimator lens, corner cube prism, optical lens, right angle prism ,ATR prism ect
4.Optical Mirrors, Dielectric Mirror, Spherical Concave or Convex Mirror, Off- Axis Parabolic Mirrors coating including Silver, Gold, Aluminum, Cooper, Nickel etc.
Besides, we also specialized in manufacturing large size prism, such as Periscope prism, Beamsplitter(Cube, Plate).
We have advanced coating machines and related equipment such as ultrasonic cleaning devices. our technical team is capable of performing various types of coating processes to meet different demand, including AR coating, HR coating, long pass coating, short pass coating , bandpass coating, anti-laser coating, waterproof coating, metal coating and conductive coating
In order to ensure highest standard quality of optical components, our company equipped with advanced testing equipment like ZYGO three-dimensional optical profilometer, laser interferometer, spectrophotometer UV-3600 and video measuring machines
The survice purpose of our company is the principle based on honesty, attention to quality, the pursuit of excellence, share value, we are willing to become your best suppliers of optical components in China.
