Fish Deboning Machine

2 year ago
255 0
Product details

Introduction of Fish Deboning Machine Bone Separator

This fish deboning machine is equipped with a meat extraction barrel and a rubber belt for meat squeezing. The mutual squeezing motion of the rolling meat extraction barrel and the transmission rubber belt squeezes the fish into the meat extraction barrel while leaving the skin and bones in the meat extraction barrel. Outside the barrel, it is sent out of the machine by a scraper.
working principle:
Using the mutual squeezing motion of the rolling meat picking tube and the rotating rubber belt, the fish is squeezed into the meat picking tube of the fish meat picking machine, while the skin and bones are left outside the meat picking tube, and the scraper is used to send it out of the machine. Powered by electric motors.
Fish Meat Separator 1

Feature of Fish Deboning Machine Bone Separator

1. Made of stainless steel, the main function is to separate fish meat from fish bones, fish head, fish scale, as a professional meat ball or fish meat ball processing machinery.

2. As for the size of holes in drum, it can be 2.5mm, 2.7mm and 3mm. We can make it according to customer request.

Fish Deboning Machine Bone Separator

Principle of Fish Deboning Machine Bone Separator

The Fish Deboning Machine Bone Separator was developed based on counter rotating belt and drum mechanism in which dressed fishes were fed to counter rotating belt and perforated drum and it gets squeezed through the holes into the cylinder under the pressure applied by the conveyor belt partially encircling the cylinder while bones and skin were retained outside of the drum and ejected through a discharge chute.

Technical sheet of fish meat separator

Fish Meat Separator 2

Technical sheet of Fish Deboning Machine Bone Separator

Model

Capacity

Power

Dimension

GMS-CR150

150-200kg/h

1.5kw

830*680*870mm

GMS-CR200

250-300kg/h

2.2kw

860*830*1060mm

GMS-CR300

350-500kg/h

2.2kw

960*830*1060mm

GMS-CR350

1000-1500kg/h

7.5kw

1300*1000*1060mm

This is an important equipment for meatball processing, it also needs the meat tumbler, sausage stuffer, meat grinder machine, meat bowl cutter and smoker oven to get final fish meatballs. Please contact me for details:
